Spray Nozzle IEC 60529 IPX3 IPX4

Spray Nozzle IEC 60529 IPX3 IPX4

  • Measurement & Analysis Instruments > Safety Instrument
  • Include ISO 17025 CNAS & ILAC Test Report
  • Item No.: LX-IPX34H
  • Made in China
  • Product description: The Spray Tester IPX 3/4 is a hand-held test device to verify protection against spraying and splashing water. The water pressure can be adjusted using the flow control knob on the device to give the

Spray Nozzle IEC 60529 IPX3 IPX4


It's strictly designed according to IEC60529 Figure 5, Used to test the waterproof performance of appliance and electric appliance with the rain protection function.


The IPX3 IPX4 Hand-held Spray Nozzle intended for use on specimens that will not fit within the diameter of the Oscillating Tube Tester.

The difference between IPX3 and IPX4 is that the baffle should be removed in the IPX4 test.






Water supply

Water flow rate is 0.05 ~ 0.15 Mpa clean water without inclusion.


Spray nozzle parameters

External diameter: Ф102 mm

spherical diameter: SФ75.5 mm

There is a middle hole and There are 24 holes in the internal circle of holes of which the included angle is 30°. There are 96 holes in the external circle of holes of which the included angle is 15°. 121 holes in total.

The hole diameter: Ф0.5 mm

It is made of brass.



IEC60529 IPX3 IPX4.





Pressure gauge



Site requirements

Dedicated IP waterproof test room, The ground should be flat with illumination, With good function of inflow and drainage.
