  • AC/DC:0-5/10KV, AC:20mA, DC:10mA Voltage Withstand Test Instrument
AC/DC:0-5/10KV, AC:20mA, DC:10mA Voltage Withstand Test Instrument

AC/DC:0-5/10KV, AC:20mA, DC:10mA Voltage Withstand Test Instrument

  • Measurement & Analysis Instruments > Safety Instrument
  • Include ISO 17025 CNAS & ILAC Calibration Certificate
  • Item No.: RK2671AM
  • Made in China
  • Product description: This high voltage test (also called dielectric strength test, hipot test, hi-pot test, breakdown test or flash test) is made to stress the device under test to an AC or DC high voltage and check that
  • INQUIRY

AC/DC:0-5/10KV, AC:20mA, DC:10mA Voltage Withstand Test Instrument


Operation condition:
Environment Temperature: 0~40°C
Relative Humidity: ≤75%
Atmospheric Pressure: 101.25KPa

Technical Index:

Item RK2671AM
Output   Voltage Range (AC/DC) 0   ~ 5 KV / 10 KV
Voltage   Resolution 10V
Voltage   Accuracy ±5%
Leakage   current (AC) 0-2/20mA
Leakage   current (DC) 0-2/10mA
Current   Resolution 0~2mA:1μA
2~20mA:10μA
Current   Accuracy ±5%
Measurement   Time Setting 0s-99s,Continuously   setting and manual
Maximum   output power 200VA
Capacitor   of Transformer 750VA
Display   Form LED   Digital Display
Power   Requirements 220V±10%,   50Hz±5%
Operation   Environment 0℃~40℃, ≤85%RH
Dimensions 300*370*200mm
Weight 14kg


Company introduction

HK LEE HING INDUSTRY CO., LIMITED are specialized in manufacturing special, custom built, test and measuring equipment for products testing as per international norms and offering calibration services and related information. Our products and services are used by research & development establishments, test laboratories, defense establishments, government institutions & manufacturing industries to fulfill the clients' requirements.


Main Products: Go Not Go Gauges, IP Tester, Test Probe Kit, Impact Test Equipment, Test Probes, Spring Hammer, IEC 61032 Test Finger, Plugs and Socket Outlet Gauge, AC Hipot Tester, IEC Test Probe, UL Test Probe, Material Flammability Tester, IP Code Tester, Impact Test Apparatus, Security Testing Machine, Lamp Cap Gauge Tester, Lampholders Gauge Tester, Plug & Socket Tester, Electrical Safety Tester, LED Test Instruments, Environmental Test Equipment, Instrument Accessories, Weighing Sensor and More.


If you require equipment to test products such as home appliances, electrical accessories like switches, sockets, connectors, etc. industrial & road lighting luminaires, automobile lighting systems or related categories, we can provide the solutions you need.
